Rivets (DIN)

Multiple rivet tools share the same position on the tool set. Click and hold the mouse on the visible tool to open the Pop-out tools list and select the desired tool.

To insert a rivet (DIN):

1.      Click the tool and mode.

2.Click to place the object, and click again to set the rotation. The first time you use the tool in a file, a properties dialog box opens. Set the default parameters. The parameters can be edited later from the Object Info palette.

Click to show/hide the parameters.

~~~~~~~~~~~~~~~~~~~~~~~~~

Large rivets

Small rivets

Tubular rivets
